Hot Selling 10 x Micro SD TF Memory Card to SATA SSD Adapter + RAID Quad 2.5 SATA Converter Sep21

Hot Selling 10 x Micro SD TF Memory Card to SATA SSD Adapter + RAID Quad 2.5 SATA Converter Sep21
  • Продавецogloszeniabochnia.info
  • Список ценUS $24.82piece
  • Продажная ценаUS $24.82piece
  • ДоставкаБесплатная доставка
  • Рейтинги4,2 (507)

Oписание продукта

The i.MX 6Quad family encompasses a quad-core platform running up to 1.2 GHz with 1 MB of L2 cache and 64-bit DDR3 or 2-ch., 32-bit LPDDR2 support. Integrated FlexCAN, MLB busses, PCI Express® and SATA-2 provide excellent connectivity, while integration of LVDS, MIPI display port, MIPI camera port and HDMI v1.4 makes it an ideal platform for leading-edge consumer, automotive and industrial multimedia applications.

SBC6XB3QD 750go

SBC6x-B3V2 750









imx6 series en 01







SBC6x-B3V2 720





SBC6x-B3V2A1 750











SBC6X-B3V2A3 750













B3V2 750interface













SBC6x B3 Series Single Board Computer

Description of part code







CM6DX1 300go.jpg

CM6QX1 300go.jpg

B3 + Core Module: CM6D5D X1B3 + Core Module: CM6Q5D X1

PN: SBC6D5D X1-B3A

PN: SBC6Q5D X1-B3A



i.MX6 Cortex A9 1Ghz

 (2 shader core)

2GB DDR3 x64 bit at 400MHz

4GB eMMC

i.MX6 Cortex A9 1Ghz

 (4 shader core)

2GB DDR3 x64 bit at 400MHz

4GB eMMC

Supply Voltage: 9 - 14V

Optimal Voltage: DC 12V, 2A

Size ( L * W ): 146*102 mm

Working Temperature: 0° to 70° C

Supply Voltage: 9 - 14V

Optimal Voltage: DC 12V, 2A

Size ( L * W ): 146*102 mm

Working Temperature: 0° to 70° C

Support software:

Linux 3.x

Android 4.x

Yocto\\Ubuntu\\QT\\Debian

Support software:

Linux 3.x

Android 4.x

Yocto\\Ubuntu\\QT\\Debian

Support Interface:

mSATA (Y)

mPCIe (Y)

USB OTG

USB 2x Ext

USB 2x Int 1with mPCIe / 1with 3G/4G

Ethernet 10/100/1000

Carema interface DVP (Y)

MIPI CSI (Y)

LVDS 4 Channel

HDMI

TFT RGB LCD interface (Y)

TF card (Y)

SDIO/HCI (Y)

Debug UART

I2C,SPI,GPIOs

Support Interface:

mSATA (Y)

mPCIe (Y)

USB OTG

USB 2x Ext

USB 2x Int 1with mPCIe / 1with 3G/4G

Ethernet 10/100/1000

Carema interface DVP (Y)

MIPI CSI (Y)

LVDS 4 Channel

HDMI

TFT RGB LCD interface (Y)

TF card (Y)

SDIO/HCI (Y)

Debug UART

I2C,SPI,GPIOs








       Packing List



    1. B3 Carrier  board      x1

    2. CM6x core module    x1



Bundle 1SBC6Q5DX1-B3A



Bundle 2SBC6Q5DX1-B3A+SD8G( system card)



Bundle 3 SBC6Q5DX1-B3A+SD8G+Power 12V 2.0A



SBC6x-B3AV2 packinglist







          About GOEMBED



GOEMBED team with experienced embedded engineers who have been engaged in ARM hardware and software design for years.

Our products include single board computers (SBC335x & SBC6x series) and CPU core modules (CM335x & CM6x series) based on TI Sitara ARM Cortex-A8 processors and Freescale i.MX 6 ARM Cortex-A9 processors. Supported by Linux / Android / Debian / Ubuntu / QT / Angstrom / WinCE 7.0 / 6.0 / uCOS. We can redesign carrier boards and SBC as your idea quickly.

GOEMBED focus on Embedded Board Solutions, providea complete new board for your specified requirement or even a turnkey solution to accelerate your new products to market.

We are your trust worthy partner on ARM embedded design services and solutions.



   More Carrier Boards

Customized based on your needs!

   ODM / OEM Services

Bring your new products to market quickly



If you need to know more and < CUSTOMIZE DESIGN >, please contact GOEMBED.com
